New Engines
KDI2504M

Kohler Diesel KDI Mechanical

KDI2504M

Available for sale outside the U.S., Canada and E.U. only, the KOHLER 1903M 42 hp, 3-cylinder engine is compatible with high-sulfur fuels and is liquid cooled with direct injection and oil control. This 4-valve-head engine is loaded with features and deliver solid performance backed by a 3-year warranty.

HP
Shaft
Cylinders
Cooling
Fuel Type
Status
55 Four Liquid Diesel New
Overview
Features
Specs
Overview

Professional Grade Design.

Liquid-cooled with direct injection, oil control, and high sulfur fuel compatibility, this powerful 4-valve-head engine is not available for sale in the U.S., Canada and E.U. It offers the many features of the common rail model but does not have a common rail or EGR.

Features

User-Friendly Maintenance.

  • One side service
  • 500 hour oil change intervals

High Power Performance.

  • 4 valves per cylinder

Quiet, Smooth Operation.

  • Hydraulic valve lifters
  • Straight tooth gear reduced pitch
  • Liquid-cooled

Reliability and Long Life Design.

  • Cast iron crankcase with vibration-absorbing bed plate
Engine Uses
Specs

Engine Type:

Four-stroke in-line, cast iron block

Model
Diesel KDI2504M
Max Power @2800 RPM hp (kW) 1 55 (41)
Displacement cu in (cc) 151.4 (2482)
Bore in (mm) 3.5 (88)
Stroke in (mm) 4 (102)
Max Torque lbs. ft (Nm)1 125.4 (170)
Compression Ratio NA
Dry Weight lbs (kg) 536.8 (244)
Oil Capacity U.S. quarts (L) 11.9 (11.3)
Lubrication
Dimensions L x W x H in 27.7 x 17.8 x 26.3
Backpressure Limit 2 --
J1995 Power hp (kW) 3 -- (--)
J1995 Torque lbs ft (Nm) 3 -- (--)
1 Max Power (hp) and Max Torque (lbs ft) specifications for Kohler general purpose engines are rated pursuant to Society of Automotive Engineers (SAE) J1940 based on gross output testing performed according to SAE J1995 without the air cleaner and muffler. Actual engine power and torque are lower and affected by accessories (air cleaner, exhaust, charging, cooling, fuel pump, etc.), application, engine speed, ambient operating conditions (temperature, humidity and altitude) and other factors. This J1940 / J1995 rating provides consistent measurement to customers who may want to control the intake and exhaust features of the engine. For more information, contact Kohler Co. Engine Engineering Department. Kohler Co. reserves the right to change product specifications, designs and standard equipment without notice and without incurring obligation.

2 Inches of H20 @ 3600 RPM WOT

3 J1995 power and torque certified by 3rd Party Witness
